Fiber Laser Chiller

Industrial Laser Cooling System

  • Process Chiller Type: Water medium, air-cooled chiller

Fiber laser chillers are designed for fiber laser equipment and provide two cooling water circuits with different temperatures to cool the laser source and optical parts separately. They keep the laser at a stable temperature, maintain consistent beam quality, and extend equipment service life. These industrial process chillers are used for fiber laser cutting machines, spot welding machines, high-frequency welding equipment, laser rust cleaning machines, laser robots, and other laser processing equipment.

Contact Us
Specification Sheet
Specifications
Model AWFL-1000 AWFL-1200 AWFL-1500 AWFL-2000
Power Supply 380V/3P+N/50Hz
Total Power kW 14.5 15 19 24
Current A 23 26 30 42
Refrigerant R22
Nominal Cooling Capacity kW 28 32 42 58
Btu/s 95500 109000 143000 198000
Heating Power kW 6000 9000
Low Temperature Water Water Tank Capacity L 450 600
Temperature Range ℃ 15-35
Control Accuracy ℃ ±1.5(AWFLH±0.1~0.2)
Max. Flow Rate L/min 120 240
Max. Pressure Mpa 0.62 0.68
Connection Size G2”
Normal Temperature Water Water Tank Capacity L 20
Temperature Range ℃ 15-35
Control Accuracy ℃ ±1.5(AWFLH±0.1~0.2)
Max. Flow Rate L/min 20
Max. Pressure Mpa 0.35
Connection Size G 1/2”
Weight kg 480 520 720 780
Dimensions mm 1600×900×1950 1800×1200×2050
Features
  • Our fiber laser chillers use a dual-temperature design that provides separate cooling temperatures for the laser source and optical parts according to their different requirements.
  • Equipped with PID control to keep the laser within a stable operating temperature range and reduce performance changes caused by temperature fluctuations.
  • Their stable temperature control reduces heat buildup inside the laser unit, lowers the risk of component aging or damage, and extends the service life of key parts.
With over a decade of dedication to industrial process cooling and thermal management for industrial equipment, we have established us as a reliable manufacturer of industrial process chillers, enclosure air conditioners, air-air heat exchangers and oil mist collectors. We understand that every production process has different thermal requirements and operational demands. From CNC machining and semiconductors to laser processing and electronics manufacturing, we deliver the industrial cooling solutions designed to keep your production and operation running with temperature consistency and thermal stability. With all industrial chillers and industrial equipment thermal control systems certified by CE and ISO, we are committed to assisting you in optimizing production efficiency, minimizing downtime and reducing operational costs.
