Industrial Gearbox Oil Chiller

Machining Equipment Oil Cooling Unit

  • Process Chiller Type: Oil medium, air-cooled chiller
  • Cooling Capacity: 2.5-10kW

Industrial gearbox oil chillers are used to control the temperature of lubricating oil inside gearbox systems in various types of machining equipment. For the cooling process, the oil circulates between the gearbox and the chiller, there the heat is removed before the oil returns to the chiller, which keeps gearbox operation stable and prevents overheating during continuous use.

Contact Us
Specification Sheet
Specifications
Model AO-100PS
Cooling Capacity (50HZ) 10000 W 8600 Kcal/h
Power Main circuit Three Phase AC 380V 50Hz
Control circuit Single Phase AC 26V 50Hz
Enclosure Paint RAL-7035
Dimensions 535×760×1467mm
Compressor JT95GBBY1L
Evaporator Plate heat exchanger
Condenser Cross-fin coil type
Fan Blade Propeller fan blade
Oil Pump Pump type (with motor) 3-Phase, induction motor 0.75-1.5 kW, 4-Pole
Rated flow (50Hz) 40 L/min
Oil Temperature Control Select one of the following two modes:
Differential temperature control mode (adjustable range: -9.9°C to +9.9°C)
Constant temperature control mode (inlet temperature setpoint range: 5°C to 40°C)
Refrigerant Control Capillary tube
Protection Devices Overcurrent protection
Phase loss & phase reversal protection
Restart prevention timer
High oil temperature protection
Low oil temperature protection
Refrigerant R22
Applicable Oil Lubricating oil, spindle oil, hydraulic oil
Temperature Range Room temperature 10°C to 45°C
Inlet temperature 10°C to 40°C
Connection Size Oil inlet G 1”
Oil outlet G 1”
Oil drain port
Weight 150kg
Standard Accessories User manual
Features
  • Continuous oil circulation between gearbox and oil chillers keeps operating temperature stable
  • Prevents overheating during long machining cycles under continuous operation
  • Maintains stable gear performance under constant load conditions
  • Compatible with BF gearboxes (Baruffaldi, Italy) and ZF gearboxes (ZF Friedrichshafen AG, Germany)
  • Improves reliability and extends service life of gearbox components
